Zinc Plate Surface Recessed Round Cross Head Screw Mild Steel Cross Drive DIN7996

Product Categories
Shanghai Summery Industrial Machine Co. , Ltd.
Contact Now

Zinc Plate Surface Recessed Round Cross Head Screw Mild Steel Cross Drive DIN7996

Brand Name : Summery

Model Number : DIN 7996

Certification : ISO 7045

Place of Origin : China,shanghai

MOQ : Negotiable

Price : Negotiation

Payment Terms : L/C, D/A, D/P, Western Union

Supply Ability : 10000000

Delivery Time : 7-10 Days

Packaging Details : Poly bags

Product Name : Cross Head Screw

Material : steel

Cross recess : Type H

Surface : Zinc plate

Project : DIN7996

Size : M6x30

Grade : 4.8

Other : ASME B18.6.3

Contact Now

No 4 , 6 , 8 , 10 , 12 A2 Stainless Steel Pozi Round Head Wood Screws DIN 7996

Dimensions No4 No6 No8 No10 No12
Head Height 2.1mm 2.35mm 28mm 3.5mm 4.2mm
Head Diameter 6mm 7mm 8mm 10mm 12mm
Thread Diameter 3mm 3.5mm 4mm 5mm 5.5mm
Driver Size PZ1 PZ2 PZ2 PZ2 PZ3

Item Name All kinds of screws
Drive philips,phil-slot,pozi,hexsocket,six-lobe,square,triangle,slotted,torx,Y & Special security drive
Material 1) Stainless Steel: SS201, SS303, SS304, SS316, SS410, SS420
2) Steel:C45(K1045), C46(K1046),C20
3) Brass:C36000 ( C26800), C37700 ( HPb59), C38500( HPb58),C27200CuZn37), C28000(CuZn40)
4) Bronze: C51000, C52100, C54400, etc
5) Iron: 1213, 12L14,1215
6) Aluminum: Al6061, Al6063 etc
7) Carbon steel:C1006,C1010,C1018,C1022,C1035K,C1045
8) Alloy steel: SCM435,C10B21,C10B33
Specification & Gauge M1 - M30
Surface Finishing (1) Zn- Plated (2) Ni-plated (3) Passivated (4) Tin-plated (5) Sandblast and Anodize (6) Chromate (7) Polish (8) Electro Painting (9) Black Anodize (10) Plain (11) Chrome plated (12) Hot Deep Galvanize(H. D. G. ) etc.
Heat Treatment (1)Tempering (2)Hardening (3)Spheroidizing (4)Stress Relieving.
Standard ISO,GB,DIN,JIS,ANSI,BSW
Manufacture Process (1)Heading (2)washer assembly (3)Threading (4)Secondary machine (5)heat treatment (6)plating (7)Anti-slipping (8)Baking (9)QA (10)Package (11)Shipping
After sales service We will follow up goods for every customer and help solve problem after sales.

Zinc Plate Surface Recessed Round Cross Head Screw Mild Steel Cross Drive DIN7996

Zinc Plate Surface Recessed Round Cross Head Screw Mild Steel Cross Drive DIN7996

Zinc Plate Surface Recessed Round Cross Head Screw Mild Steel Cross Drive DIN7996
